Details

• Platform

  Moterra Neo
• Model Name

  Moterra Neo 4
• Model Code

  C65411U

Frameset

• Frame

  150mm travel, SmartForm C2 Alloy, Cannondale Tuned Suspension, removable downtube battery, internal cable routing, 148x12mm thru-axle, post mount brake, tapered headtube
• Fork

  RockShox 35 Silver R, 150mm, Solo Air, 15x110mm stealth thru-axle, tapered steerer, 51mm offset
• Headset

  Integrated Sealed Bearing, Tapered
• Rear Shock

  RockShox Deluxe Select R, DebonAir

E-System

• Drive Unit

  Shimano EP8
• Battery

  Shimano BT-E8036, 630Wh
• Charger

  Shimano Battery Charger 2A
• Display

  Shimano SC-EM800, Bluetooth enabled

Drivetrain

• Rear Derailleur

  SRAM SX Eagle
• Front Derailleur

  N/A
• Shifters

  SRAM NX Eagle, 12-speed
• Chain

  SRAM SX Eagle, 12-speed
• Crank

  FSA E-Bike, 165mm, SRAM Eagle, 34T Steel
• Rear Cogs

  SRAM PG-1210, SX Eagle, 11-50, 12-speed

Brakes

• Brakes

  TRP Slate G4 4 Piston hydraulic disc, 200/200mm rotors
• Brake Levers

  TRP hydraulic disc

Wheels

• Rims

  WTB STX i25 TCS, 32h, tubeless ready
• Spokes

  Stainless steel, 14g
• Tires

  Maxxis Rekon, 29 x 2.6″, 60TPI Exo
• Tire Size

  2.6
• Wheel Size

  29
• Hubs

  (F) Shimano MT400, 15x110mm thru-axle / (R) Shimano MT400, 12x148mm thru-axle
• Front Tire

  Maxxis Rekon, 29 x 2.6″, 60TPI Exo
• Rear Tire

  Maxxis Rekon, 29 x 2.6″, 60TPI Exo

Components

• Handlebar

  Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
• Stem

  Cannondale 3, 3D Forged 6061 Alloy, 1-1/8″, 31.8, 7°
• Grips

  Fabric Funguy
• Saddle

  Cannondale Ergo XC
• Seatpost

  TranzX dropper, internal routing, 31.6, 100mm (S), 120mm (M), 130mm (L-XL)
