Descriere
SPECIFICATIONS
-
Introducing the SCOTT Ransom. Our latest version of Ransom was uncompromisingly engineered for maximum downhill performance and an all-time confidence inspiring ride. Killer geometry paired with a supernatural suspension kinematic result in a bike that doesn’t take “no” for an answer. Don’t hold yourself hostage, ride Ransom.
Please note that bike specifications are subject to change without prior notice.
condition of usage 5Example Downhill, dirt jump, freeride
Please check the detail for more information -
Frame
Ransom Carbon HMX
Integrated Suspension Technology, 6 Link kinematic, Adjustable head angle
Syncros Cable Integration System
BB92, UDH Interface, 12x148mm with 55mm Chainline, MX Ready -
Fork
FOX Podium Factory Grip X2 Air, Kashima
HSC – LSC – HSR- LSR adjustable, 20x110mm
44mm offset, tapered steerer
170mm travel -
Rear Shock
FOX FLOAT X NUDE Factory EVOL Piggy Back Trunnion
Kashima, SCOTT custom w. travel, geo adj.
3 modes: Climb-Ramp Control-Descend
Custom large Air volume, Comp & Reb. Adj.
Travel 170-130-Climb, T205X65mm, Bearing Hardware -
Remote System
TracLoc Technology
Rear Suspension & Dropper Remote
3 Rear Suspension modes
-
Rear Derailleur
SRAM X0 Eagle AXS Transmission 12 Speed
Wireless Electronic Shift System -
Shifters
SRAM AXS Rocker Pod Controller -
Crankset
SRAM X0 Eagle Transmission
Bash guard, DUB, 55mm CL, 32T -
Chainguide
SCOTT custom -
BB-Set
SRAM DUB PF 92 MTB Wide, shell 41x92mm -
Chain
SRAM CN X0 Eagle Transmission -
Cassette
SRAM X0 Eagle XS 1295 Transmission 10-52 -
Brakes
SRAM Maven Silver 4 Piston Disc -
Rotor
SRAM HS2 Rotors F&R 200mm -
Handlebar
Syncros Hixon iC SL Carbon, 25mm rise
back sweep 8°, 780mm, 40mm
Syncros Endurance lock-on grips -
Seatpost
Syncros Duncan Dropper Post 1.5S, Travel Adjust, 31.6mm
S size 140mm, M size 180mm, L & XL size 210mm -
Seat
Syncros Tofino 1.5
Titanium Rails -
Headset
Syncros – Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB -
Wheelset
Race Face Turbine R 30, 110×20, 148×12 rear, 29″, 28H, Tubeless Ready Rims, XD driver
Syncros Axle w/Removable Lever with Tool -
Front Tire
Schwalbe Magic Mary 29×2.5″, Trail, Radial, Ultra Soft, Tubeless ready
120TPI Foldable Bead -
Rear Tire
Schwalbe Albert 29×2.5″, Gravity, Radial, Soft, Tubeless ready
120TPI Foldable Bead -
Extras
SRAM AXS Powerpack, Syncros Eco Sealant -
Accessories
Syncros IS Matchbox kit
Syncros IS tubeless Handlebar tool
Syncros Multi-tool Matchbox 8 -
Approx weight in KG
15.9 (Tubless setup without matchbox IS ) -
Approx weight in LBS
35.05 (Tubless setup without matchbox IS ) -
Max. System Weight
130kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
